Ref. 04229


635.00 € 635.0 EUR Precio con iva: 768.35 € 635.00 €

635.00 €

  • Supply Voltage
  • Dimensions
  • Usable electrodes MMA
  • Usable electrodes TIG
  • Fuse
  • Protection index
  • Intensity at 60%(100%) a 40ºC
  • Intensity MAX.
  • Ieff
  • Standards
  • Regulation board
  • Weight
  • Absorved power max.
  • Regulation
  • Voltage range
  • Duty Cycle at 40ºC
  • Ventilation
  • OCV
  • Imax

This combination does not exist.

· 200Amp Inverter at 60%.
· Equipped with welding accessories.
· Valid for generator.
· TIG by Lift-Arc.
· Digital front.
· DDR Anti-Shock construction.

Share this product:

Main features:

Talking about professional welding is talking about the iCON product line. Due to its patented and innovative DDR construction design, due to its great capacity to work under intensive conditionsand demanding environments and due to its unmatched results in terms of reliability and performance, this is undoubtedly the best option for the most demanding professionals.

· Arc-Sense regulation offers stability and control regardless of the electrode-material distance.
· Double automatic ventilation that only acts when the equipment requires it.
· Stand-by position, when the equipment is not in operation.
· Equipped with Anti-stick, Arc-Force, Hot Start and Lift-Arc (TIG) devices.
· Can be connected to generators with a wide range of working voltages.

Intensity at 60%(100%) a 40ºC 200A (140A)
Intensity MAX. 200A
Regulation 10 - 200A
Duty Cycle at 40ºC 60%
Usable electrodes MMA 1,6 - 4,00 mm
Usable electrodes TIG 1,0 - 3,2 mm
Supply Voltage 230V - 1Ph
Fuse 16A
Ieff 29,7A
Absorved power max. 8,5KVA
Voltage range 180V - 300V
Imax 42A
Dimensions 430x175x325mm
Protection index IP23C
Standards EN-60974-1, EN-60974-10
Regulation board SOLTER ICON DIGITAL
Weight 6,4Kg
Ventilation DOBLE - AUTO
